频率：24MHZ
尺寸：7.0×5.0mm
AAS24M000000DHJ18H,24MHZ,AA系列晶振,STD无源晶振,7050mm,美国进口晶振,STD Crystal,石英水晶振动子,贴片石英晶体,四脚贴片晶振,SMD晶体谐振器,无源晶振,7050晶振,24MHZ轻薄型晶振,尺寸7.0×5.0mm,频率24MHZ,负载18pF,工作温度-40~+85℃,高性能晶振,高品质晶振,低耗能晶振,低损耗晶振,无铅环保晶振,微处理器晶振,测试设备晶振,仪器设备,数码相机晶振.
AAS24M000000DHJ18H,24MHZ,AA系列晶振,STD无源晶振,7050mm特点:
低成本低损耗SMD贴片晶体类型
具有更严格的公差和稳定性
符合ROHS/无铅
AAS24M000000DHJ18H,24MHZ,AA系列晶振,STD无源晶振,7050mm 参数表
| Frequency Range | 24 MHz | |||||||||
| Frequency Tolerance | ± 50 PPM (Standard) | |||||||||
| Frequency Stability | ± 50 PPM ( Standard ) | |||||||||
| Operating Temperature Range | 0EC to 70EC ( Standard ) | |||||||||
| Load Capacitance ( CL ) | 12pF to 50pF & Series | |||||||||
| Shunt Capacitance | 7pF Maximum | |||||||||
| Drive Lavel | 100uWatt Maximum | |||||||||
| Aging | ±3 PPM per year Maximum | |||||||||
AAS24M000000DHJ18H,24MHZ,AA系列晶振,STD无源晶振,7050mm 尺寸图
